PRODUCTS FOR METAL AND
ELECTRONIC PARTS POLISSNING
The Fine finishing film consists of a smooth base film coated with superfine abrasive by means of electrostatic coating. This structure achieves a high precision level that cannot be obtained with fabric or paper products, while having excellent abrasive performance and durability.
This abrasive film, taking advantage of thinness, uniformness, and strength, eliminates the need of dressing due to clogging. The super finishing of this product achieves stable processing without any roughness on the surface in order to supply a new polishing surface consecutively at a constant speed.
The SDFR-40 series coated with diamond abrasive by means of electrostatic coating is especially one of the original products of Sankyo-Rikagaku.
This series is applicable for polishing hard materials, such as ceramic and carbide, which are difficult to polish with regular abrasives.
- Various types of roll polishing
- Automobile parts
(Crankshafts, camshafts, balance shafts, fuel injection parts, automatic transmission parts, transfer/mechanical LSD, etc.) - Automobile coating polishing
- Flat displays and magnetic heads
- Plastic lenses
- Optical fiber ends and creation of analytical samples
Kind:Fine finishing film | Micron/particle size | |||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
100 | 80 | 60 | 40 | 30 | 20 | 15 | 12 | 9 | 5 | |||
Type | Minerals | Backing | 120 | 240 | 320 | 400 | 600 | 800 | 1000 | 1500 | 2000 | 3000 |
MAF | White aluminum oxide | 75μ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ||
100μ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | |||||
125μ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ||||
MCF | Carborundum | 100μ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ||||
125μ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ||||||
VAF | White aluminum oxide | 125μ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | |||
VCF | Carborundum | 125μ | ◯ | ◯ | ◯ | ◯ | ◯ | |||||
SAF | White aluminum oxide | 125μ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | |||
DCF | Carborundum | 100μ | ◯ | ◯ | ◯ | ◯ | ||||||
DAF | White aluminum oxide | 100μ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ||
FAF | 75μ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ||||
SDF | Diamond | 100μ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ | ◯ |
